Handle Recommendation
Guidance on the correct handle size for your door
|
65-FD |
Installation
|
|
| Dimensions | 1981 x 686 x 44mm |
| Lipping Around Edges | 11mm |
| Trimming Allowance - Top | 2mm |
| Trimming Allowance - Bottom | 2mm |
| Trimming Allowance - Each Side | 2mm |
| Hinge Type Required | 4 Inch Butt Hinge |
| Number of Hinges | 3 required |
Need To Know
|
|
| Brand | XL Joinery |
| Range | Palermo |
| Collection | Palermo Premium |
| Door type | Fire Doors |
| FD Rating | FD30 |
| Use | Internal |
Construction
|
|
| Material | Oak |
| Finish | Unfinished |
| Veneer | |
| Veneer Material | American White Oak (Grade A) |
| Veneer Thickness | 6MM |
| Texture | Woodgrain |
| Inlay Material (Grooves) | Oak |
| Lipping Material (Edges) | Oak |
| Core Type | Solid Core |
| Weight | 32kg |
Glazing
|
|
| Glazing Type | Glazed Doors |
| Transparency | Clear glass |
| Glass Shape | fully glazed |
| Glass Cut | Flat Glass |
| Specification | Toughened 6mm Safety Glass |
| Compliance | British Standard BS EN 12150 |
Design
|
|
| Door Style | Modern |
| Colour | Brown |
Question from Timothy: Asked on 11/08/2026 Does the trimming max of 2 mm
Mean you can't cut more off to fit
Hi, Yes, that’s correct. The 2 mm trimming allowance is the maximum that can be removed from any one edge. You can trim up to 2 mm from the top, bottom, or each side, but you should not remove more than 2 mm from a single edge, as this could affect the FD30 fire rating and manufacturer’s warranty.
Thank you.
